康明斯发电机组出售28〜1875 kVA
产品型号：
Prime power：20/25 KW /kVA
Standby power：22/28 KW /kVA
Frequency / RPM：60HZ / 1800 RPM
Engine model：4B3.9-G1
Length.Width.Height： 2240 mm * 950 mm * 1500 mm
Weight：1180 KG
Noise：TBD @7M
Genset Basic parameters
| Standby Power (kW/kVA) | 22/28 | |
| Prime Power (kW/kVA) |
20/25
|
|
| Frenquency (Hz) |
60
|
|
| Phase & Wires |
3*4
|
|
| Rated Voltage (V ) |
208~480
|
|
| Rated Current (A) |
69.4~30.1
|
|
| Panel Type |
Digital Panel
|
|
| Fuel Consumption (75% Load) L/h |
5.0
|
|
| Fuel Consumption (100% Load) L/h |
6.2
|
|
| Noise level dB(A) | Open Type |
85±2
|
| Silent Type |
65 ±2
|
|
| Overall L*W*H dimension (mm) | Open Type |
1580 *650 *1146
|
| Silent Type |
2240 *950 *1500
|
|
| Weight （kg） | Open Type |
732
|
| Silent Type | 1180 | |
Engine |
|
| Engine Manufacturer |
CUMMINS
|
| Engine Model |
4B3.9-G1
|
| Rated Power (kW/HP) |
30/41
|
| Engine Type |
4 Cycle;in-line;4 Cylinder Diesel
|
| Displacement (L) |
3.9
|
| Air intake way |
Naturally aspirated
|
| Governer method |
Mechanical
|
| Starting System |
Electrical Starting
|
| Starting Voltage (V) | DC24V |
| Cylinder Bore* Stroke (mm) |
102*120
|
| Compression Ration | 16.5:1 |
| Cooling System | Water cooled |
| Capacity of cooling water (L) | 7.2 |
| Lubrication System | Pressure splashed |
| Lube Capacity (L) | 11.0 |
| Fuel Type | To conforms to BS2869 class A2 or GB 252-2000 |
| Lube oil brand |
15W40-CH4 Upgrade
|
Alternator |
|
| Alternator Manufacturer |
STAMFORD
|
| Alternator Model |
PI 144D
|
| Control System |
AVR
|
| Excitation Mode |
Brushiess Self-regulating
|
| Insulation System |
Class H
|
| Protetion |
IP44
|
| Rated Power Factor |
0.8
|
| Stator winding | Standard NO.6 |
| Temperature grade |
H/F
|
| Voltage Regulation（%） | ±0.5 |
| Satisfying Standardization | IEC60034,NEMA MG1.22,ISO 8528, CSA,UL1446,UL 1004B |
